B-Box (RED® KOMODO™) attaches to the camera-right BP-9 battery slot and provides a breakout for the camera’s EXT connector. Battery Slide Pro V-Mount or Gold Mount for RED KOMODO can be used simultaneously and custom right-angle LEMO compatible connector allows for neat cable run. Canon BP-9 batteries could also be attached in camera-left slot while B-Box is used.
Available ports include:
R/S (3pin Fischer)
Simple run/stop for Handgrip Trigger Box, Simple 3pin Fischer Trigger Cable, etc.
No power available
Devices like ARRI WCU-4 may require CTRL port interface with cable K2.0015758
Pin1:GND, pin2:N/C, pin3:GPI
Timecode (5pin LEMO)
Standard wiring for timecode in/out
Pin1:GND, pin2:LTC-IN, pin3:N/C, pin4:N/C, pin5:LTC-OUT
CTRL (4pin LEMO)
Standard wiring for RED CTRL
Pin1:GND, pin2:UART-RX, pin3:GPO, pin4:UART-TX
5V (USB)
5V available at 500mA maximum
Power may need to be enabled in camera menu
Genlock (BNC)
Standard wiring for genlock
Center:signal, shell:GND
